  • Air / Water Heat Exchanger RK 2192-230V

Air / Water Heat Exchanger RK 2192-230VSeifert compressor cooling units for 19 "applications are available with cooling capacities (L35L35) from 550 W up to 1 kW.

Product Feature

Order Number2192000
Brand Name19" RACK
ColourRAL 7035
Housing MaterialMild steel, powder coated
Ingress ProtectionIP 54
NoteWith thermostatic solinoid controlled valve
ApprovalsCE


Technical Data

Cooling capacity L35W10 (200 l/h)1 kW
Cooling capacity L35W10 (500 l/h)1.2 kW
Refrigerant / GWPWater, light oils or similar
Operating Temperature Range1°C - 72°C
Air flow volume (system / unimpeded)165 / 575 m³/h @ 50 Hz
180 / 625 m³/h @ 60 Hz
Mounting19" mounting
Dimensions A x B x C (D+E)

A = Height | B = Width | C = Depth

89 (2U) x 443 x 408 mm
Weight13 kg
Voltage / Frequency230 V ~ 50/60 Hz
Starting current1 A
Max. current0.4 A
Max. power90 W
Pressure water circuit10 bar
Water connectionRp 1/4” - inside thread with 2 connectors for pipe internal diameter of 10 mm. OUTLET (female) & INLET (male) flexible tube for RK/LW 1/4” thread, 510 mm length
Fuse4 A (T)
Short-circuit current rating5 kA
ConnectionPlug


Downloads

Datasheet                        230v    120v

Instruction Manual           PDF

CAD files                        STEP File    (Right click, save as)

Certifications                    PDF EC Declaration
