SoliTherm Outdoor air conditioning unit OC-4410-230V. Protection ratings make the unit ideal for outdoor cabinets, ensuring top performance with minimal maintenance.
Product Feature
| Order Number | 4410918 |
| Brand Name | Compact Outdoor |
| Colour | RAL 7035 |
| Housing Material | Stainless steel AISI 304 (V2A) |
| IP protection class to EN 60 529 | IP 56 |
| Note | The unit has an internal MCB (miniature circuit breaker) accessible by removing the front cover |
| Approvals | CE |
Technical Data
| Cooling capacity L35L35 (EN14511-3) | 1600 W (L40L45) |
| Compressor type | Rotary piston compressor |
| Refrigerant / GWP | R134a / 1430 |
| Refrigerant charge | 750 g / 26.5 oz |
| High / low Pressure | 21 / 6 bar 305 / 88 psig |
| Air flow volume (system / unimpeded) | Ambient air circuit: 530 / 1200 m³/h Cabinet air circuit: 375 / 550 m³/h |
| Operating Temperature Range | +20°C - +50°C |
| Mounting | Standalone |
| Dimensions A x B x C (D+E) A = Height | B = Width | C = Depth | 550 x 557 x 500 mm |
| Weight | 50 kg |
| Voltage / Frequency | 230 V ~ 50/60 Hz |
| Current L35L35 | 4.2 A |
| Starting current | 15.5 A |
| Max. current | 4.7 A |
| Nominal power L35L35 | 1.02 kW |
| Fuse | 10 A (T) |
| Short-circuit current rating | 5 kA |
| Connection | 2 x 3 m 180 mm flexible plastic duct |
Downloads
Instruction Manual
PDF
CAD files
STEP File (Right click, save as)
Certifications PDF EC Declaration
Video
Installation
Outdoor Radar Dome Air Conditioner OC 4410-230V
- Brands Seifert
- Product Code: 4410918
- Availability: 6 Weeks +
-
£0.00
